Table 73: Parts and Tools Required for Connecting an EX Series Switch to Earth
Ground (continued)
Additional
InformationScrewdriver
Screws and
Washers
Grounding Lug
Specifications
Grounding Cable
Requirements
Earthing
Terminal
LocationSwitch
See “Special
Instructions to
Follow Before
Connecting Earth
Ground to a Switch”
on page 160.
Phillips (+)
number 2
Two 10-32
x .25 in. screws
with #10
split-lock
washer—
not provided
Two #10 flat
washers—
not provided
Panduit
LCC10-14BWL or
equivalent—
not provided
14 AWG (2 mm²),
minimum 90°C wire,
or as permitted by
the local code
Left side of
chassis
EX4500
See “Special
Instructions to
Follow Before
Connecting Earth
Ground to a Switch”
on page 160.
Phillips (+)
number 2
Two 10-32
x .25 in. screws
with #10
split-lock
washer—
not provided
Two #10 flat
washers—
not provided
Panduit
LCC10-14BWL or
equivalent—
not provided
14 AWG (2 mm²),
minimum 90°C wire,
or as permitted by
the local code
Left side of
chassis
EX4550
Phillips (+)
number 2
Two ¼-20
x 0.5 in. screws
with #¼”
split-washer
—provided
Two #¼” flat
washers—
provided
Panduit
LCD2-14A-Q or
equivalent
—provided
The grounding cable
must be the same
gage as the power
feed cables and as
permitted by the
local code.
Rear panel
of chassis
(on lower
left side)
EX6210
Phillips (+)
number 2
Two ¼-20
x 0.5 in. screws
with #¼”
split-washer
—provided
Two #¼” flat
washers—
provided
Panduit
LCD2-14A-Q or
equivalent
—provided
6 AWG (13.3 mm²),
minimum 60°C wire,
or as permitted by
the local code
Left side of
chassis
EX8208
See “Special
Instructions to
Follow Before
Connecting Earth
Ground to a Switch”
on page 160.
Phillips (+)
number 2
Two ¼-20 x
0.5 in. screws
with #¼”
split-washer
—provided
Two #¼” flat
washers—
provided
Panduit
LCD2-14A-Q or
equivalent
—provided
2 AWG (33.6 mm²),
minimum 60°C wire,
or as permitted by
the local code
Two
earthing
terminals:
Left side
of
chassis
Rear
panel of
chassis
EX8216
159Copyright © 2015, Juniper Networks, Inc.
