The following sample configuration shows an SRX5400 Services Gateway chassis with various power
supplies and:
•
Two SRX5K-SPC-4-15-320 (SPC2) Services Processing Card (SPC) (slots 1 and 2)
•
One SRX5K-MPC (IOC2) with two MICs installed in it (slot 1/0)
•
One switch control board SRX5K-SCB (SCB1) or SRX5K-SCBE (SCB2) and one Routing Engine
SRX5K-RE-13-20 (RE1) or SRX5KRE-1800X4 (RE2) installed in it (SCB slot 0)
1. Calculate the power requirements (usage) as shown in Table 33 on page 155.
Table 33: Sample Power Requirements for an SRX5400 Services Gateway
Power RequirementPart NumberChassis Component
40 WSRX5400-CHASBase system
75 WSRX5400-FANFan tray
570 WIOC2
SRX-MIC-2X40-QSFP
SRX-QSFP-40G-SR4
MPC - slot 1/0
585 W * 2 = 1170 WSCP2SPC - slots 1 and 2
150 W
90 W
SCB1 with
RE1
Or
SCB 0
>150 W
90 W
SCB2 with
RE2
2095 WTotal power requirement
2020 WTotal power requirement excluding cooling system
2. Evaluate the power budget. In this step, we check the required power against the maximum output
power of available power supply options.
