Section 3: Functions and features Series 2280 Precision DC Power Supply Reference Manual
3-6 077085503 / March 2019
Output delay
You can set a delay before turning on the output or turning off the output. The delay can range from
0.001 s to 10 s.
Using the front panel:
1. Press the MENU key.
2. Under Source, select Settings.
3. Select the button next to Output Delay. The delay window is displayed.
4. Select On to enable the output delay.
5. Select the button next to Delay Rise and enter a value.
6. Select the button next to Delay Fall and enter a value.
Using SCPI commands:
To set output on and off delays, send the following commands:
OUTP:DEL:RIS 2
OUTP:DEL:FALL 3
To enable the output delay, send the command:
OUTP:DEL:STATe ON
Slew rate
The slew rate determines the rate at which the voltage changes to a new programmed setting. You
can specify the rising rate and falling rate for the voltage changes.
Using the front panel:
1. Press the MENU key.
2. Under Source, select Settings.
3. Select the button next to Slew Rise and enter a value
4. Select the button next to Slew Fall and enter a value.
Using SCPI commands:
To specify the rising rate for the voltage source, send the command:
:VOLT:SLEW:RIS 100
To specify the falling rate for the voltage source, send the command:
:VOLT:SLEW:FALL 100
