Series 2280 Precision DC Power Supply Reference Manual Section 1: Introduction
077085503 / March 2019 1-3
Key features
The Series 2280 has the following features:
 High current resolution and sensitivity to measure a wide range of load currents
 6½-digit measurement resolution to enable a wide range of measurements while on one current range
 Fast current measurements to test or study load current pulses as narrow as 100 μs
 Linear mode, low noise output
 Color TFT display with icon-based and soft key user interface
 Data logging and analysis with graphical display and statistics for trend analysis
 Up to nine groups of user-definable lists with up to 99 steps for each list
 GPIB, USB-TMC, and LAN LXI interfaces for automated test development
 Filtering to reduce noise on load current readings
 Digital I/O for rich trigger functions
 Direct parameter entry using the numeric keypad, soft keys, or the navigation wheel
 Front-panel USB-A connector for flash-drive support
 Front and rear inputs with remote sense connections on the rear panel connector
 Overcurrent, overvoltage, and over temperature protection
 Compact, 2U, half rack, stackable form factor fits easily in a test rack
Precision measurement DC power supply. 32 V, 6 A
Precision measurement DC power supply. 60 V, 3.2 A
