Series 2280 Precision DC Power Supply Reference Manual Section 3: Functions and features
077085503 / March 2019 3-9
Buffer fill status
You can determine buffer fill status from the front panel. As shown in the following figure, the active
buffer indicator displays buffer fill status.
Figure 58: Buffer indicator
Setting reading buffer size and buffer mode
To configure the buffer, configure the following settings:
Set the buffer size
Set the buffer fill mode
Buffer size
The initial buffer capacity is 100 readings for the power supply function.
The initial buffer capacity is 2500 readings for the battery test and battery simulation functions.
You can resize the default buffer (power supply function only).
Stored readings and statistics are deleted when you change the capacity of a buffer.
