Keithley 2280 Series Reference Manual

Section 7: SCPI command reference Series 2280 Precision DC Power Supply Reference Manual
7-72 077085503 / March 2019
:SENSe[n]:<function>:REFerence:STATe
This command enables or disables a relative offset value.
Type
Affected by
Where saved
Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
0 (OFF)
Usage
:SENSe[n]:<function>:REFerence:STATe <state>
:SENSe[n]:<function>:REFerence:STATe?
[n]
Channel number: For single-channel instruments, the value is 1
<function>
The measurement function to which this setting applies:
 Concurrent: CONCurrent[:DC]
 Current: CURRent[:DC]
 Voltage: VOLTage[:DC]
<state>
Disable the relative offset: OFF or 0
Enable the relative offset: ON or 1
Details
This attribute enables or disables relative measurements. When relative measurements are enabled,
all subsequent measured readings are offset by the relative offset value calculated when you acquire
the relative offset value.
Each returned measured relative reading is the result of the following calculation:
Displayed reading = Actual measured reading - Relative offset value
For concurrent measurements, the offset value is applied only to current measurements.
Example
:SENS:FUNC "VOLT"
:SENS:VOLT:REF:ACQ
:SENS:VOLT:REF:STATe ON
Set the measurement function to voltage with a
relative offset of 5 V and enable the relative offset
function.
Also see
:SENSe[n]:<function>:REFerence:ACQuire (on page 7-71)
