Series 2280 Precision DC Power Supply Reference Manual Section 3: Functions and features
077085503 / March 2019 3-35
Configuring a list
To set up a list from the front panel, select options from the SOURCE LIST screen.
To configure a list on the front panel:
1. Press the Menu key.
2. Under Source, highlight the List icon using either the navigation control or the soft keys.
3. Press the ENTER key. The SOURCE LIST screen is displayed.
Figure 71: Source List screen
4. Select the button next to List and press the ENTER key. The List Location screen is displayed.
5. Select a list location where you want to save the list and press the ENTER key. The Series 2280
supports up to 9 list locations. You can also import a predefined list from an external USB flash
drive. For details, refer to Importing a list from an external USB flash drive (on page 3-37).
6. Use the Insert or Copy button to increase the points in the list. For details, refer to Inserting or
copying points from the front panel (on page 3-36). Use the Delete button to delete the points.
For details, refer to Deleting points from the front panel (on page 3-36).
You can use the Insert button to add one point with default settings before each specified point. The
default settings are: 0.000 V, 0.100 A, 0.100 s. You can also use the Copy button to copy the
selected settings for the point and insert a new point with the same settings before each point.
For an empty list, you can add the first point by selecting point 1 and pressing the ENTER key. The
first point is configured to the default settings.
