Keithley 2280 Series Reference Manual

Section 7: SCPI command reference Series 2280 Precision DC Power Supply Reference Manual
7-26 077085503 / March 2019
:CALCulate[1]:<function>:STATe
This command enables or disables the math operations.
Type
Affected by
Where saved
Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
0 (OFF)
Usage
:CALCulate[1]:<function>:STATe <state>[,<channel>]
:CALCulate[1]:<function>:STATe? [<channel>]
<function>
The measurement function to which this setting applies:
 Concurrent: CONCurrent[:DC]
 Current: CURRent[:DC]
 Voltage: VOLTage[:DC]
<state>
Enable math operation: ON or 1
Disable math operation: OFF or 0
<channel>
The channel number (default value is CH1):
 Channel 1: CH1
Channel 2: CH2
Details
When this command is set to on, the math operation specified by the math format command is
performed before completing a measurement.
Example
:CALC:VOLT:FORM MXB
:CALC:VOLT:KMAT:MMF 0.80
:CALC:VOLT:KMAT:MBF 50
:CALC:VOLT:KMAT:MUN 'C'
:CALC:VOLT:STATE ON
Set the math function for voltage measurements to mx + b.
Set the scale factor for voltage measurements to 0.80.
Set the offset factor to 50.
Set unit to 'C'
Enable the math function.
Also see
:CALCulate[1]:<function>:FORMat (on page 7-21)
:CALCulate[1]:<function>:KMATh:MBFactor (on page 7-22)
:CALCulate[1]:<function>:KMATh:MMFactor (on page 7-23)
:CALCulate[1]:<function>:KMATh:MUNits (on page 7-25)
