Series 2280 Precision DC Power Supply Reference Manual Appendix D: Status model
077085503 / March 2019 D-19
Measurement Instrument Summary Event Register
The bits of the Measurement Instrument Summary Event Register are described in the following
figure and table.
Figure 133: Series 2280 Measurement Instrument Summary Event Register
Bit
Decimal
value
Bit name
When set, indicates the following has
occurred:
0
1
ROF
Reading overflow
1 through 5
Not used.
Not used
NA
6
64
RAV
Reading is available.
7
128
BHF
Buffer is half-full.
8
256
BF
Buffer is full.
9
512
BTF
Buffer is three-quarters full.
10
1024
BQF
Buffer is one-quarter full.
11 through 15
Not used
Not used
NA
