Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 3: Functions and features

2651A-901-01 Rev. A / March 2011 3-9

To save the reading buffer data:

1. From the front panel, press the STORE key, and then select SAVE.

2. Select INTERNAL to save to internal nonvolatile memory.

3. Select one of the following:

• SMUA_BUFFER1

• SMUA_BUFFER2

4. The front panel displays Saving... This may take awhile.

5. Press the EXIT (LOCAL) key to return to the main menu.

Saving the reading buffer to the USB flash drive

After the measurements are complete, you can save the reading buffer data to a flash drive.

To save the reading buffer data to a USB flash drive:

1. Insert the USB flash drive into the USB port.

2. Press the STORE key and use the navigation wheel

to select SAVE. Then select USB1.

3. Select one of the following file formats:

• CSV

• XML

4. Use the navigation wheel to select the desired reading buffer.

5. Use the navigation wheel

to change the file name.

6. Press the navigation wheel

or the ENTER key to save the file.

7. Press the EXIT (LOCAL) key to return to the main menu.

Recalling readings

To recall the data stored in a reading buffer:

1. Press the RECALL key, and then select DATA or STATISTICS.

2. Select the buffer to display. The data (or statistics) will be displayed.

If data is being recalled, the reading display is on the top left, and the buffer location number is on the

right. The source values are positioned at the lower left side of the display (if enabled); the timestamp

(if used) is positioned at the lower right side. If statistics are being recalled, the information will include

values for MEAN, STD DEV, SAMPLE SIZE, MINIMUM, MAXIMUM, and PK-PK. The source display

field will identify the buffer: SrcA1 (buffer 1) or SrcA2 (buffer 2).

Buffer location number

The buffer location number indicates the memory location of the source-measure reading. For

example, location #000001 indicates that the displayed source-measure reading is stored at the first

memory location.
