Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 3: Functions and features

2651A-901-01 Rev. A / March 2011 3-53

Detecting trigger events using the wait() function

All of the Model 2651A trigger objects (except for SMUs) have built-in event detectors that monitor for

trigger events. The event detector only monitors events generated by that object and cannot be

configured to monitor events generated by any other trigger object. Using the wait() function of the

trigger object causes the Model 2651A instrument to suspend command execution until a trigger

event occurs or until the specified timeout period elapses.

For example, use trigger.blender[N].wait(Y) to suspend command execution until an event

blender generates an event, where N is the specific event blender and Y is the timeout period. After

executing the wait() function, the event detector of the trigger object is cleared.

The following programming example illustrates how to suspend command execution while waiting for

various events to occur:

-- Wait up to 10 seconds for a front-panel TRIG key press.

display.trigger.wait(10)

-- Wait up to 60 seconds for timer 1 to complete its delay.

trigger.timer[1].wait(60)

-- Wait up to 30 seconds for input trigger to digital I/O line 10.

digio.trigger[10].wait(30)

Using the assert() function to generate trigger events

Certain trigger objects can be used to generate output triggers on demand. These trigger objects are

the digital I/O lines, TSP-Link synchronization lines and the LAN.

The programming example below illustrates how to generate an output trigger using the assert()

function of the trigger object:

-- Generate a falling-edge trigger on digital I/O line 3.

digio.trigger[3].mode = digio.TRIG_FALLING

digio.trigger[3].assert()

-- Generate a rising edge trigger on TSP-Link sync line 1.

tsplink.trigger[1].mode = tsplink.TRIG_RISINGM

tsplink.trigger[1].assert()

-- Generate a LAN trigger on LAN pseudo line 6.

lan.trigger[6].mode = lan.TRIG_EITHER

lan.trigger[6].assert()
