Section 2: General operation Model 2651A High Power System SourceMeter® Instrument Reference Manual
2-20 2651A-901-01 Rev. A / March 2011
The following table contains descriptions of the configuration menus, as well as cross-references to
related information. To select a menu, press the CONFIG key and then the front-panel key associated
with the desired menu (see the description column in the following table).
Quick Tip
Press the EXIT (LOCAL) key to return to a previous menu.
Configuration
menu
To access, press
the CONFIG key
and then:
Description For more information, see:
SRC SRC V-source sense, low range;
I-source low range; and highC
mode
Range (on page 2-65)
MEAS MEAS V and I-measure sense, low
range; autozero
Range (on page 2-65)
LIMIT LIMIT V-source and I-source
compliance limits
Compliance limit (on page 2-12)
SPEED SPEED Measurement speed (NPLC) Speed (on page 2-71)
REL REL Set relative values Rel (on page 3-1)
FILT FILTER Control digital filter Filters (on page 3-3)
OUTPUT OUTPUT ON/OFF Set off-state, control digital I/O Output-off states (on page 2-59)
TRIG TRIG Set trigger in, count, interval,
and delay
Triggering (on page 3-32)
STORE STORE Set buffer count and
destination
Source-measure concepts (on page 4-
2)
Setting values
Setting a value
There are two ways to adjust a value: the Navigation wheel method or Numeric entry method
(using the keypad). To use the keypad, the keypad feature must be enabled. When using either
method, use the following editing techniques:
Quick Tip
To set a value to zero, press the 0000 numeric entry key. To toggle the polarity of a value, press the
+/– numeric entry key.
