Keithley 2651A Reference Manual

Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-150 2651A-901-01 Rev. A / March 2011
Details
Once a pulse train has been configured and assigned to a tag, it is often desirable to inspect the settings of this
preconfigured pulse train. The QueryPulseConfig() command can be used for this purpose.
This function will return a table containing the various settings associated with the tag input parameter.
Return values:
tostring()
A function that returns most elements in a string convenient for printing
tag
Identifying tag for this pulse train
smu
The SMU configured for pulsing
func
Pulse function:
smuX.OUTPUT_DCAMPS or
smuX.OUTPUT_DCVOLTS
bias
Pulse bias level
level
Pulse level for non sweeping pulses
start
Starting level for sweep pulses
stop
Ending level for sweep pulses
limit
Limit value
ton
On time in seconds
toff
Off time in seconds
points
The number of points in this pulse train
buf
Reference to buffer containing measurement data
sync_in
The sync_in digio line, if used
sync_out
The sync_out digio line, if used
sourcevalues
A table containing the source value for each point in the pulse train
