Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference
2651A-901-01 Rev. A / March 2011 7-233
Also see
Triggering (on page 3-32)
smuX.trigger.endsweep.action
This attribute sets the action of the source at the end of a sweep.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes SMU reset
Instrument reset
Not saved smuX.SOURCE_IDLE
Usage
action = smuX.trigger.endsweep.action
smuX.trigger.endsweep.action = action
action
The source action at the end of a sweep; set to one of the following values:
0 or smuX.SOURCE_IDLE: Sets the source level to the programmed (idle) level at
the end of the sweep
1 or smuX.SOURCE_HOLD: Set to have the source stay at the level of the last step
X
SMU channel (for example, smua.trigger.endsweep.action applies to SMU
channel A).
Details
Use this attribute to configure the source action at the end of the sweep. The SMU can be programmed to return
to the idle source level or hold the last value of the sweep.
Example
smua.trigger.endsweep.action =
smua.SOURCE_IDLE
Sets SMU Channel A to return the source
back to the idle source level at the end of a
sweep.
Also see
Triggering (on page 3-32)
smuX.trigger.IDLE_EVENT_ID
This constant contains the idle event number.
Type TSP-Link accessible Affected by Where saved Default value
Constant Yes
Usage
eventID = smuX.trigger.IDLE_EVENT_ID
eventID
The idle event number
X
SMU channel (for example, smua.trigger.IDLE_EVENT_ID applies to SMU
channel A)
