Usage
enableRegister = status.system2.condition
enableRegister = status.system2.enable
enableRegister = status.system2.event
enableRegister = status.system2.ntr
enableRegister = status.system2.ptr
status.system2.enable = enableRegister
status.system2.ntr = enableRegister
status.system2.ptr = enableRegister
enableRegister
The system summary 2 register's status. A zero (0) indicates no bits set; other
values indicate various bit settings
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary registers.
They are set using a constant or a numeric value, but are returned as a numeric value. The binary equivalent of
the value indicates which register bits are set. In the binary equivalent, the least significant bit is bit B0, and the
most significant bit is bit B15. For example, if a value of 1.29000e+02 (which is 129) is read as the value of the
condition register, the binary equivalent is 0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are
set.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
** > > > > > > > > > > > > > > *
0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 1
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets
(on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
Bit Value Description
B0
status.system2.EXTENSION_BIT
status.system2.EXT
Bit B0 decimal value: 1
B1
status.system2.NODE15
Bit B1 decimal value: 2
B2
status.system2.NODE16
Bit B2 decimal value: 4
B3
status.system2.NODE17
Bit B3 decimal value: 8
B4
status.system2.NODE18
Bit B4 decimal value: 16
B5
status.system2.NODE19
Bit B5 decimal value: 32
B6
status.system2.NODE20
Bit B6 decimal value: 64
B7
status.system2.NODE21
Bit B7 decimal value: 128
B8
status.system2.NODE22
Bit B8 decimal value: 256
B9
status.system2.NODE23
Bit B9 decimal value: 512
B10
status.system2.NODE24
Bit B10 decimal value: 1024
B11
status.system2.NODE25
Bit B11 decimal value: 2048
B12
status.system2.NODE26
Bit B12 decimal value: 4096
B13
status.system2.NODE27
Bit B13 decimal value: 8192
B14
status.system2.NODE28
Bit B14 decimal value: 16384
B15 Not used Not applicable
