Appendix C: LAN concepts and settings Model 2651A High Power System SourceMeter® Instrument Reference Manual
C-16 2651A-901-01 Rev. A / March 2011
2. Type a name to identify the connection (for example, My Instrument) and then click OK.
3. In the Connect To dialog box, click the Connect using drop-down list and then select TCP/IP
(Winsock).
Figure 125: Connect To dialog box
My Instrument
192.168.1.101
TCP/IP (Winsock)
23
4. In the Host address field, type the instrument's IP address (for example, 192.168.1.101) .
5. Type 23 in the Port number field, and then click OK. The HyperTerminal program window
displays.
6. From the HyperTerminal program window, click File > Properties.
