Model 2651A High Power System SourceMeter® Instrument Reference Manual Appendix E: Status model
2651A-901-01 Rev. A / March 2011 E-27
Status configuration (enable) commands
The following commands (sent from the master node) enable the appropriate register bits for the
above example:
Node 15 status registers: The following commands enable the current limit events for SMU A of node
15:
node[15].status.measurement.current_limit.enable = 6
node[15].status.measurement.enable = 2
node[15].status.node_enable = 1
The affected status registers for the above commands are indicated by labels A, B and C (see
following figure).
System summary registers: The following commands enable the required system summary bits for
node 15:
status.system2.enable = 2
status.system.enable = 1
The affected system summary registers for the above commands are indicated by labels D and E
(see following figure).
