Keysight E4980A/AL Precision LCR Meter 49
Display Format
MEAS DISPLAY Page
3-
Equivalent parallel and serial combinations
The combinations of primary and secondary parameters, including the
equivalent parallel and series combinations, are listed below.
Rdc
2
DC resistance
1. This parameter can be set only when the E4980A is equipped with option 001.
2. This parameter can be set only when the E4980A/AL is equipped with either
option 001, 030/032, 050/052, 100 or 200.
Table 3-3 Secondary parameter
Parameter Description
Table 3-4 Measurement function
Primary
parameter
Series mode Parallel mode
Z Z-r
Z-d
-----
Y ----- Y-r
Y-d
C Cs-D
Cs-Q
Cs-Rs
Cp-D
Cp-Q
Cp-G
Cp-Rp
L Ls-D
Ls-Q
Ls-Rs
Ls-Rdc
Lp-D
Lp-Q
Lp-G
Lp-Rp
Lp-Rdc
R R-X -----
G ----- G-B
Primary parameter Secondary parameter
Vdc Idc
Measurement function Vdc-Idc does not have the series mode and parallel
mode.
