Keysight InfiniiVision HD3-Series Oscilloscopes
User's Guide
14 Measurements
To quickly add 10 common measurements / 186
To make automatic measurements / 187
To edit measurements / 188
Measurements Summary / 188
Voltage Measurements / 190
Time Measurements / 196
Count Measurements / 203
Mixed Measurements / 204
FFT Analysis Measurements / 205
Measurement Thresholds / 207
Measurement Window / 209
Measurement Statistics / 209
Measurement Limit Testing / 211
The Measure > menu lets you make automatic measurements on waveforms. Some
measurements can only be made on analog input channels.
The results of the last 10 selected measurements are displayed in the
Measurements window in the Results area.
When you add a measurement, it appears at the bottom of the Measurements list
dialog, and markers that show the portion of the waveform being measured are
automatically displayed. You can change the measurement for which markers are
displayed by selecting the measurement in the list or by selecting the
measurement in the Markers dialog box.
Post Acquisition Processing
In addition to changing display parameters after the acquisition, you can perform all of the
measurements and math functions after the acquisition. Measurements and math functions
will be recalculated as you pan and zoom and turn channels on and off. As you zoom in and out
on a signal using the horizontal scale knob and vertical volts/division knob, you affect the
resolution of the display. Because measurements and math functions are performed on
displayed data, you affect the resolution of functions and measurements.
