Note that when inverted output is enabled, the waveform's offset is not
inverted.
• Aux Out — Specifies the signal that is output on the oscilloscope's rear panel
AUX OUT BNC connector:
• Triggers — Each time the oscilloscope triggers, a rising edge occurs on
AUX OUT. The rising edge is delayed 1.06 μs from the oscilloscope's trigger
point. The output level is 0-5 V into an open circuit, and 0-2.5 V into 50 Ω.
• Mask — The pass/fail status is evaluated periodically. When the evaluation of
the testing period results in a failure, the trigger output pulses high (+5 V).
Otherwise, the trigger output remains at low (0 V).
• Waveform Generator Sync Pulse — All of the waveform generator output
functions (except DC, Noise, and Cardiac) have an associated Sync signal:
To edit arbitrary waveforms
When Arbitrary is selected as the generated waveform type (see "To select
generated waveform types and settings"
on page 249), select Edit Waveform... to
open the WaveGen: Arbitrary Waveform Editor dialog box.
This dialog box has two formats depending on whether there are currently defined
arbitrary waveform points.
When No Points
Exist
The WaveGen: Arbitrary Waveform Editor dialog box lets you set up an arbitrary
waveform in one of these ways:
• Set initial number of points — When selected, to create a new arbitrary waveform:
Waveform Type Sync Signal Characteristics
All waveforms except
DC, Noise, and Cardiac
The Sync signal is a TTL positive pulse that occurs when the waveform
rises above zero volts (or the DC offset value).
DC, Noise, and Cardiac N/A
