Keysight InfiniiVision HD3 Series - Rising Edge Count; Falling Edges Count; Mixed Measurements; Area

204 Keysight InfiniiVision HD3-Series Oscilloscopes User's Guide
14 Measurements
Rising Edge Count
The Rising Edge Count measurement is an edge count for the selected waveform
source.
This measurement is available for analog channels.
Falling Edges Count
The Falling Edges Count measurement is an edge count for the selected waveform
source.
This measurement is available for analog channels.
Mixed Measurements
• "Area" on page 204
Area
Area measures the area between the waveform and the ground level. Area below
the ground level is subtracted from area above the ground level.
The Full Screen measurement interval variation measures the value on all
displayed data points.
Negative pulse count
T
Negative area
N cycles
Positive area
