52 Keysight InfiniiVision HD3-Series Oscilloscopes User's Guide
2 Horizontal Controls
To copy search setups
Except for Frequency Peak and Protocol event search setups, you can copy search
setups to trigger setups and vice-versa.
1 From the menu, choose Analyze > Search....
2 In the Search dialog box, select On.
3 Select the Search Type, and use the additional controls to set up the selected
search type.
4 Select Copy....
5 In the Copy dialog box:
• Select Copy to Trigger to copy the setup for the selected search type to the
same trigger type. For example, if the current search type is Pulse Width,
selecting Copy to Trigger copies the search settings to the Pulse Width trigger
settings and selects the Pulse Width trigger.
• Select Copy from Trigger to copy the trigger setup for the selected search type
to the search setup.
• To undo a copy, select Undo Copy.
The buttons in the Copy dialog box may not be available when one of the
settings cannot be copied or there is no trigger type that corresponds to the
search type.
Navigating the Time Base
You can use the Analyze > Navigate... menu item, Navigate dialog box, and
navigation controls to navigate through:
• Captured data (see
"To navigate time" on page 52).
• Search events (see "To navigate search events" on page 53).
• Segments, when segmented memory acquisitions are turned on (see "To
navigate segments"
on page 53).
To navigate time
When acquisitions are stopped, you can use the navigation controls to play
through the captured data.
1 From the menu, choose Analyze > Navigate....
2 In the Navigate dialog box, select the Time navigation type.
3 Select the navigation buttons to play backward, stop, or play
forward in time. You can select the or buttons multiple times to speed
up the playback. There are three speed levels.
