Measurements 14
Keysight InfiniiVision HD3-Series Oscilloscopes User's Guide 189
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
"Amplitude" on page 191
"Area" on page 204
"Average" on page 194 Yes, Full
Screen
"Base" on page 192
"Bit Rate" on page 199 Yes
"Burst Width" on page 199
"Counter" on page 198 Yes Not valid for math waveforms.
"Delay" on page 200 Yes Measures between two sources.
"Duty Cycle" on page 199 Yes
"Fall Time" on page 200
"Frequency" on page 197 Yes
"Maximum" on page 191 Yes
"Minimum" on page 191 Yes
"Rising Edge Count" on
page 204
"Falling Edges Count" on
page 204
"Positive Pulse Count" on
page 203
Yes
"Negative Pulse Count" on
page 203
Yes
"Overshoot" on page 192
"Peak-Peak" on page 191 Yes
"Period" on page 197 Yes
"Phase" on page 201 Measures between two sources.
"Preshoot" on page 193
"Ratio" on page 196 Measures between two sources.
"Rise Time" on page 199
"Slew Rate" on page 205
"DC RMS" on page 194
