Kollmorgen AKD series Installation Manual

AKD Installation | 7 Technical description and data
7.10 Fusing
EU Cartidge Fuses US Cartridge Fuses
Types gS (gRL) or gG (gL), 400 V/500 V, time-delay Class J, 600 V AC 200 kA, time-delay.
The fuse must be UL and CSA listed.
Cartidge fuse holders: Combined with the standard fuse blocks, finger safe fuse holders
must be used according to IEC 60529.
Examples Bussmann: CH Series Modular Fuse Holders, class J, 3 poles: CH30J3, CH14J3
Example Ferraz: Ultrasafe Fuse holders, class J, 3 poles: US3J3I
7.10.1 External power supply fusing
Drive
Model
Max.
Ampere rating
Example class J
Bussmann
Example class J
Ferraz Shawmut
AKD-x00306 10A (Time-Delay) LPJ10SP/DFJ10 AJT10/HSJ10
AKD-x00606 15A (Time-Delay) LPJ15SP/DFJ15 AJT15/HSJ15
AKD-x01206 15A (Time-Delay) LPJ15SP/DFJ15 AJT15/HSJ15
AKD-x02406 30A (Time-Delay) LPJ30SP/DFJ30 AJT30/HSJ30
AKD-x00307 6A (Time-Delay) LPJ6SP/DFJ6 AJT6/HSJ6
AKD-x00607 10A (Time-Delay) LPJ10SP/DFJ10 AJT10/HSJ10
AKD-x01207 15A (Time-Delay) LPJ15SP/DFJ15 AJT15/HSJ15
AKD-x02407 30A (Time-Delay) LPJ30SP/DFJ30 AJT30/HSJ30
AKD-x04807 60A (Time-Delay) LPJ60SP/DFJ60 AJT60/HSJ60
7.10.2 External 24 V supply fusing
Drive
Model
Max.
Ampere rating
Example class J
Bussmann
Example class J
Ferraz Shawmut
all AKD 8A (Time-Delay) LPJ8SP/DFJ8 AJT8
7.10.3 External regen resistor fusing
Drive Model Ampere
rating@240V
Ampere
rating@480V
UL region
example:
CE Region
example:
AKD-x003 to 012 10A 40A Bussmann
FWP-xxA14F
Siba 110V to 400V:
gRL xxA (gS)
Siba 400V to 480V:
aR xxA
AKD-x024 15A 50A
AKD-x048 - Fritzlen DC Powerswitch FPS (➜ # 111)
7.10.4 External DC Bus link fusing
Drive Model Ampere
rating
UL region
example:
CE Region
example:
AKD-x003 to 024 50A Bussmann
FWP-50A14F
Siba
110V to 400V: gRL 50A (gS)
400V to 480V: aR 50A
AKD-x048 125A Bussmann
FWP-125A14F
Siba
400V to 480V: aR 125A
40 Kollmorgen | kdn.kollmorgen.com | October 2017

Kollmorgen AKD series Specifications

General

Continuous Current	Up to 180 A
Control Modes	Position, Velocity, Torque
Communication Interfaces	EtherCAT, CANopen, Modbus TCP/IP
Feedback Options	Resolver, Encoder
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1)
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overtemperature
Switching Frequency	8 kHz, 16 kHz
Ambient Temperature	0°C to 40°C
Operating Temperature	0 - 40 °C (derating may apply)
Humidity	5% to 95% non-condensing
