Installing additional RAM
5. Remove the existing module (B), by gently rotating it forward as
shown in the diagram.
6. Insert the new SIMM module (C) into the slot that was origi-
nally empty, as shown in the diagram. Line up the lower side of
the module with the slot base, then rotate the module up, and
delicately push until it is firmly seated in place. Be sure the mod-
ule is correctly inserted. If not, extract it and repeat the opera-
tion.
7. Now re-insert the SIMM module (B) that you removed in step
5, using the same method as used with the new module (C).
8. Close and secure the compartment cover by reversing the opera-
tions seen on step 2.
B
C
B

Korg PA1X Specifications

General

Polyphony	62 voices
Sound Engine	HI synthesis (Hyper Integrated)
Display	TouchView graphical touch screen
Sequencer	16-track sequencer
Storage	floppy disk drive
Connectivity	MIDI In/Out/Thru, USB
Outputs	Headphones
Inputs	Microphone Input
