Installing the Inverter
Installing
the Inverter
29
SV0550-0750iS7 (400 V)
Units: mm (inch)
Inverter
Capacity
W1
W2
H1
H2
H3
D1
D2
A
B
C
SV0550–0750
iS7-4
370.1
(14.57)
312.8
(12.31)
663.5
(26.12)
631.4
(24.85)
24.1
(0.94)
DCR type
10
(0.39)
10
(0.39)
M8
373.3
(14.69)
211.5
(8.32)
Non-DCR type
312.4
(12.29)
150.6
(5.92)
