Figure 387 — Rocker Arm Shaft and J-Tech™ Engine Brake Components
1. Cylinder Head Cover
2. Spacer
3. Long Capscrew
4. Spherical Jam Nut
5. Exhaust Adjusting Screw
6. Standard Adjusting Screw and Jam Nut (Inlet Valves)
7. Cylinder Head
8. Exhaust Valve Yokes
9. Actuator Pin Assembly
10. Rocker Arm Shaft Assembly
11. Oil Supply Screw (New Style Design with Integral Check
Valve)
12. Slave Piston Adjusting Screw
13. Engine Brake Assembly
