DESCRIPTION AND OPERATION
Page 23
12
Figure 12 — MASS Flow System (with One-Piece Cool Tube Assembly)
1. EGR Cool Tube
2. Upper Clamp
3. Coupling Hose and Clamps
4. Coupling Adapter
5. Mixer Tube
6. EGR MASS Flow Module (mounts on back of EECU
cooling plate)
7. MASS Flow Sensors
8. Lower Clamp
9. Coupling Hose Clamp
10. Coupling Hose
11. EGR Cooler
5-111.bk Page 23 Monday, July 10, 2006 2:26 PM
