Page 34
DESCRIPTION AND OPERATION
27
Figure 27 — Dual Exhaust Springs (to Mid-Year 2003)
28
Figure 28 — Dual Exhaust Springs (Mid-Year 2003 and
Later)
1. Spring Rotator (Tip-End)
2. Hardened Spring
Washer
3. Exhaust Spring (Outer)
4. Exhaust Spring (Inner)
1. Exhaust Spring (Outer)
2. Exhaust Spring (Inner)
3. Valve Rotator (Bottom)
5-111.bk Page 34 Monday, July 10, 2006 2:26 PM
