M A E D A Mini-Crawler Crane Section 4 – AUXILIARY WINCH MONITOR
1/2019 MC285C-3 4-133
AUXILIARY WINCH MONITOR
Home Screen
Fig.4-354
1 - Auxiliary Winch Display
NOTICE: This section describes only indications
and operations that differ from normal use when
using an auxiliary winch.
For more information on indications and switch
operations not described in this section, see
“Home Screen” on page 4-10.
Auxiliary Winch Display
The display will change depending on the auxiliary
winch setting.
Fig.4-355
