Maeda MC285C-3 - Rated Total Load Chart for Auxiliary Winch

Section 3 – RATED TOTAL LOAD CHARTS Mini-Crawler Crane M A E D A
3-22 1/2019 MC285C-3
Rated Total Load Chart for Auxiliary Winch
1. The diagram of working radius and lifting height has been made allowing for no deflection in the
boom.
2. Rated total load chart is based on working radius with boom deflection and raised load taken into
consideration.
3. Rated total load is shown with the mass of single fall hook (20 kg) included.
4. If boom (3) is extended to any extent, work should be performed within the capacity for “5.575 m
Boom”.
5. When more than one half of the first mark is exposed from the boom (2), work should be carried
out within the performance for the “7.075 m Boom”.
6. When more than one half of the second mark is exposed from boom (2), work should be carried
out within the performance for the “8.575 m Boom”.
7. Rough operation of crane is very dangerous. Always try to operate safely.
8. The Rated Total Load Chart capacities are based on using the factory supplied Standard Wire Rope.
If you replace the wire rope, use the correct specification, that meets or exceeds the standard wire
rope strength and specification.
9. Standard wire rope specification: 6xWs (26) IWRC, 8 mm diameter, 108 m
Specified breaking load: 48.1 kN
Rated Total load Chart - Searcher Hook - Position : SH3
The unit of loads: kg
2.535 m Boom
2.536 – 4.075 m Boom
4.076 – 5.575 m Boom
5.576 – 7.075 m Boom
7.076 – 8.575 m Boom
Load
radius
(m)
Loaded
Boom
angle
(deg)
Outrigger position
Loaded
Boom
angle
(deg)
Outrigger position
Loaded
Boom
angle
(deg)
Outrigger position
Loaded
Boom
angle
(deg)
Outrigger position
Loaded
Boom
angle
(deg)
Outrigger position
Load
radius
(m)
MAX
Other
than MAX
MAX
Other
than MAX
MAX
Other
than MAX
MAX
Other
than MAX
MAX
Other
than MAX
1.4
52.5
900
900
73.5
900
900
1.4
1.5
50.0
900
900
72.5
900
900
1.5
2.0
33.5
900
900
67.0
900
900
2.0
2.5
50.0
850
580
2.5
3.0
40.5
850
440
56.0
850
460
3.0
3.5
27.5
800
320
49.5
800
340
3.5
3.6
24.5
800
300
48.0
780
320
58.0
770
350
3.6
3.9
8.5
800
260
44.0
740
270
55.5
710
290
3.9
4.0
42.5
730
260
54.5
690
280
61.0
500
280
4.0
4.5
34.0
580
200
49.5
530
220
57.5
350
210
4.5
5.0
24.0
480
140
44.0
430
170
53.5
290
160
5.0
5.4
7.0
480
100
39.0
390
120
50.0
250
130
5.4
5.5
37.5
380
110
49.0
250
130
5.5
6.0
30.5
330
100
44.5
220
110
6.0
6.5
21.0
300
70
39.5
180
80
6.5
6.9
6.0
280
50
35.5
150
50
6.9
7.0
34.0
150
50
7.0
7.5
27.5
130
7.5
8.0
19.0
100
Prohibited
8.0
8.4
5.5
100
8.4
