Maeda MC285C-3 - TRAVEL CONTROLS

Section 4 – TRAVEL CONTROLS Mini-Crawler Crane M A E D A
4-4 1/2019 MC285C-3
TRAVEL CONTROLS
Control Location
Fig. 4-2
1 - Accelerator Lever
2 - L. H. Travel Lever/Locking lever
3 - R. H. Travel Lever/Locking lever
4 - Starter Switch
5 - Emergency Engine Stop Switch (EMO)
6 - Horn Switch
7 - Working Light Switch
8 - Preheat Lamp
