Section 3 – RATED TOTAL LOAD CHARTS Mini-Crawler Crane M A E D A
3-16 1/2019 MC285C-3
Rated Total Load Chart for
Standard Specification
1. All rated total loads are indicated in
kilograms.
2. This load radius shown in this chart is based
on practical working including boom
deflection due to loading. The crane user
must calculate and compensate for boom
deflection as the load is lifted.
3. Deductions from rated total loads must be
made for the weight of hook block, ball/hook,
slings, rigging or other suspended gear.
4. The slewing range will be restricted if the
outrigger angle is not at the standard
extension.
5. The Rated Total Load Chart capacities are
based on using the factory supplied Standard
Wire Rope. If you replace the wire rope, use
the correct specification, that meets or
exceeds the standard wire rope strength and
specification.
6. Standard wire rope specification: 6xFi (29)
IWRC, 10 mm diameter, 48 m
Specified breaking load: 41.2 kN
Rated Total Load Chart–4 Falls
Rated Total load Chart - 4 falls
Hook block mass weight 30 kg standard supplied Maeda hook block or ball.
To Next Page
