HOISTS MLC650 SERVICE/MAINTENANCE MANUAL

5-14

Published 09-09-16, Control # 229-09

FIGURE 5-5

Item Description

1 Lever

2Roller

3 Capscrew

4Drum

5Jam Nut

6 Adjusting Screw

7Screw (qty 4)

8 Limit Switch

9 Limit Switch Cover

Cable

Restraint Connector

11 Mounting Tab

12 Return Spring (qty 3)

13 Eyebolt (qty 3)

14 Eyebolt Jam Nut (qty 6)

3 to 4 Wraps of Wire

Rope Remaining on

Drum

View D

View B

View C

35 mm

44 mm

View A

Jumper

Wire
