UNDERCARRIAGE MLC650 SERVICE/MAINTENANCE MANUAL
8-22
Published 09-09-16, Control # 229-09
Crawler/Carbody Pin Pullers Hydraulic
Schematic (Remote Control)
Item Description
1 Selector Solenoid Valve
2 Six-Section Lower Accessory Valve Assembly
3 Carbody Manual Control Manifold
FIGURE 8-12
