MLC650 SERVICE/MAINTENANCE MANUAL HYDRAULIC SYSTEM
2
2
Drum Brakes Release Manifold and Solenoid
Valves
Drums 1, 2, 3, 4 and 6
Drum 5
Drum 3 shown. Other drums similar.
FIGURE 2-15
Item Description
1 Drum Brake Release Manifold
2Flow Control
3 Poppet Solenoid Valve
4 Sequence Valve
5 Directional Control Solenoid
Item Description
1 Drum Brake Release Manifold
2 Directional Control Solenoid
FIGURE 2-16
