Reference Only
ACCESSORIES MLC650 SERVICE/MAINTENANCE MANUAL
10-22
Published 09-09-16, Control # 229-09
Rigging Winch (Drum 0) Hydraulic
Schematic
The hydraulic schematic is shown in the neutral state.
Item Description
1 Upperworks Jacking and Rigging Winch Valve Assembly
2 Brake Shuttle Valve
3 Counterbalance Valve
4Drum Brake
FIGURE 10-16
