Manitowoc MLC650 Service Maintenance Manual

Reference Only
ACCESSORIES MLC650 SERVICE/MAINTENANCE MANUAL
10-34
Published 09-09-16, Control # 229-09
Self-Assembly Cylinder Hydraulic
Schematic
The hydraulic schematic is shown in the neutral state.
Item Description
1 Mast Assist and Self-Assembly Cylinder Valve Assembly
2 Load-Hold Valve (set at 269 bar [3900 psi])
FIGURE 10-26
