Manitowoc MLC650 - Lower Accessories Valve Assembly (Without Jacking Valve)

Reference Only
HYDRAULIC SYSTEM MLC650 SERVICE/MAINTENANCE MANUAL
2-16
Published 09-09-16, Control # 229-09
Lower Accessories Valve Assembly
(Without Jacking Valve)
FIGURE 2-19
Item Description
1 Left Crawler Pin—Extend
2 Right Crawler Pin—Extend
3 Left Crawler Pin—Retract
4 Right Crawler Pin—Retract
