ACCESSORIES MLC650 SERVICE/MAINTENANCE MANUAL
10-30
Published 09-09-16, Control # 229-09
Mast Assist Cylinders Hydraulic Schematic
(Setup Remote and Switch Control)
FIGURE 10-23
Item Description
1 Mast Assist and Self-Assembly Valve Assembly
2 Load-Hold Counterbalance Valve (set at 275 bar [4000 psi])
3 Cylinder Counterbalance Valve (set at 248 bar [3600 psi]) (qty 4)
