ELECTRICAL SYSTEM MLC650 SERVICE/MAINTENANCE MANUAL
3-20
Published 09-09-16, Control # 229-09
Control Module Test Voltages
Pump and Motor Voltages and Currents
Table 3-4 shows the voltages and currents of the pumps,
hoists, and travel motors.
Table 3-4. Pump and Motor Voltages and Currents
Pumps
1.6 or 8.8 V
DC
nominal
200 to 600 mA
1,2
Hoist Motors
4.5 to 10 V
DC
180 mA to 450 mA
1,2
Travel Motors
0 or 24 V
DC
nominal
0 or 600 mA nominal
1
VPC Motors
0 or 24 V
DC
nominal
0 or 600 mA nominal
1
Note 1: Resistance increases as the temperature rises on
the pump or motor solenoid coil, resulting in decreased
current values when measured with a meter. The listing in
the table is the current range for a 21°C (68.9°F) coil.
Note 2: The node regulates displacement of the pump or
motor with a PWM output. The values represent the
beginning and end of the control range.
