Manitowoc Published 09-09-16, Control # 229-09 10-35
MLC650 SERVICE/MAINTENANCE MANUAL ACCESSORIES
10
10
Self-Assembly Cylinder Hydraulic
Schematic (Setup Remote and J4 Joystick
Control)
FIGURE 10-27
Item Description
1 Mast Assist and Self-Assembly Cylinder Valve Assembly
2 Load-Hold Valve (set at 269 bar [3900 psi])
