Manitowoc MLC650 - Rotating Bed Jacks Hydraulic Schematic (Remote Control)

Reference Only
Manitowoc Published 09-09-16, Control # 229-09 10-13
MLC650 SERVICE/MAINTENANCE MANUAL ACCESSORIES
10
10
Rotating Bed Jacks Hydraulic Schematic
(Remote Control)
FIGURE 10-10
Item Description
1 Upperworks Jacking and Rigging Winch Valve Assembly 2 Counterbalance Valve (qty 4) (set at 248 bar [3600 psi])
