Input/Output—Small (IOS) Module
IOSs control the devices connected to them and
communicate with CSMs or CCMs connected to their bus.
IOSs have half the device capacity as input/output—large
(IOL) modules.
There are two IOS modules on the crane (Figure 3-9
):
• MWIOSB22 (carbody)
• MWIOSA22 (cab)
FIGURE 3-9
Item Description
1MWIOSB22
2MWIOSA22
