Table 5-3. Legend for Figure 5-22 and Figure 5-23
Item Description
1 Accessory Valve Manifold
2 Pump 1 Charge Pressure Diverter Valve (directional control)
3 Charge Pressure Check Valve (1,7 bar [25 psi])
4 Pump 1 Pressure Transducer (drum 1 psi)
5 Drum 1/Drum 6 Diverter Valve (directional control)
6 Accumulator
7 Drum Pawl Actuator
8 Drum Pawl Assembly
9 Drum Pawl Control Manifold
10 Loop Flushing Valve (6 GPM at 200 psi)
11 Drum Brake Release Solenoid Valve (2-position 4-way directional control)
12 Pilot-Operated Sequence Valve (balanced piston)
13 Manually Operated Service Valve (2-position 2-way poppet control)
14 Flow Control Valve (6 GPM)
15 Hydraulic Pump (variable 130 cc)
16 Drum Hoist Gearbox and Brake Assembly
17 Drum 6 Brake Pressurized (disengaged)
18 Pump 9 Pressure Transducer (acc systems psi)
19 Drum 1/Drum 6 Selector Solenoid Valve
