Manitowoc Published 09-09-16, Control # 229-09 5-59
MLC650 SERVICE/MAINTENANCE MANUAL HOISTS
5
55
f. Slowly pump oil into the gearbox until the oil level is
halfway up the oil level sight gauge (5). Do not
overfill.
g. When the gearbox is filled, remove the quick-drain
drainer assembly hose.
h. Fasten the dust cap to the quick-drain valve.
i. Install the breather plug.
12. Check the oil level after operating the hoist. If necessary,
add oil through the fill port (2).
13. Thoroughly clean the quick-drain drainer assembly hose
and store it in the parts box.
