Manitowoc MLC650 Service Maintenance Manual

Reference Only
HOISTS MLC650 SERVICE/MAINTENANCE MANUAL
5-64
Published 09-09-16, Control # 229-09
FIGURE 5-33
Location of components at boom top is shown
Location of components at boom cap, EUBP, and luffing jib top is similar
Item Description Item Description
1 Upper Boom Point 7 Weight
2 Lower Boom Point 8 Weight
3 Block-Up Limit Switch Enclosure 9 Lift Plate
4 Block-Up Limit Switch Enclosure 10 Weight Ball
5 Chain 11 Load Block
6 Chain 12 Chain, Shackle, and Pin
