HOISTS MLC650 SERVICE/MAINTENANCE MANUAL
5-66
Published 09-09-16, Control # 229-09
Item Description
1a Spring
1b Spring
2 Eyebolt (qty 2)
3 Setscrew
4 Limit Switch Shaft
5 Limit Switch Actuator Arm
6 Actuating Lever
7 Block-Up Limit Assembly Cover
8 Limit Switch
FIGURE 5-34
Dim. C = 24,1 mm
Dim. A = 26,4 mm
Dim. B = 22,6 mm
