HOISTS MLC650 SERVICE/MAINTENANCE MANUAL
5-74
Published 09-09-16, Control # 229-09
Item Description
1Drum
2 Pressure Roller
3Spring
4 Spring Retainer Bar
5Cotter Pin
6Pin
7a Lock Nut
7b Lock Nut
8 Washer
9Cotter Pin
10 Pin
11 Plate
12 Pressure Roller Arm
View A
FIGURE 5-41
View B
View C
Roller Acting on
Barrel
Roller Acting on
Rope Layer
Dim. B = 11 mm
Dim. A = 289 mm
Marks
