INTRODUCTION MLC650 SERVICE/MAINTENANCE MANUAL
1-8
Published 09-09-16, Control # 229-09
HSC11-06 Drum 2 Left Brake Release PC112-15
HSC11-07 Drum 6 Pawls In PC112-14
HSC11-08 Drum 6 Pawls Out PC112-4
HSC11-09 Drum 6 Brake Release PC112-3
HSC11-12 Drum 5 Pawls In PC112-25
HSC11-13 Drum 5 Pawls Out PC112-6
HSC11-14
Drum 5 Left and Right Brake
Releases
PC112-16
HSC30-03 Drum 3 Right Brake Release PC302-24
HSC30-05 Swing Brake Release PC302-25
HSC30-07 Travel Brake Release PC302-7
HSC30-11
Front Frame Pin Pusher
Extend
PC302-27
HSC30-12
Front Frame Pin Pusher
Retract
PC302-9
HSC30-16
Left Mast Cylinder PSl
Reducing
PC302-29
HSC30-17
Right Mast Cylinder PSI
Reducing
PC302-19
HSC30-18
Self-Assembly Cylinder
Extend
PC301-5
HSC30-19
Self- Assembly Cylinder
Retract
PC301-6
HSC30-20 Mast Raise PC301-7
HSC30-21 Mast Lower PC301-8
HSC31-03 VPC Actuator Brake PC312-24
HSC31-04 VPC1/VPC2 Diverter PC312-6
HSC31-05 VPC Tray Brake PC312-25
HSC31-10 Left Cylinder Stowage Extend PC312-8
HSC31-11 Left Cylinder Stowage Retract PC312-27
HSC31-12
Right Cylinder Stowage
Extend
PC312-9
HSC31-13
Right Cylinder Stowage
Retract
PC312-28
HSC31-14 Right Rear Jack Extend PC312-18
HSC31-15 Right Rear Jack Retract PC312-10
HSC31-18 Rigging Winch Spool In PC311-5
HSC31-19 Rigging Winch Spool Out PC311-6
HSC32-02 Drum 4 Pawls Out PC322-5
HSC32-03 Drum 4 Pawls In PC322-24
Table 1-1. Hydraulic Solenoid Identification
Solenoid
Number
Description
Pin
Number
HSC32-04 Drum 4 Right Brake Release PC322-6
HSC33-11
Left Mast Cylinder Directional
Control
PC332-27
HSC33-12
Right Mast Cylinder
Directional Control
PC332-9
HSC34-17 Cooler Fan Pump PC342-19
HSC35-02 VPC Actuator Pin Extend PC352-5
HSC35-03 VPC Actuator Pin Retract PC352-24
HSC35-09 Beam/Foot Upper Pin Extend PC352-17
HSC35-10 Beam/Foot Upper Pin Retract PC352-8
HSC35-11 Beam/Foot Lower Pin Extend PC352-27
HSC35-12 Beam/Foot Lower Pin Retract PC352-9
HSD01-07 Main Right Strut Collapse PD011-2
HSD01-02 Main Left Strut Collapse PD011-7
HSD01-08 Jib Stop Cylinder Collapse PD011-15
Table 1-1. Hydraulic Solenoid Identification
Solenoid
Number
Description
Pin
Number
